Panasonic CS-E18NKR Service Manual

27
Type Cross-Flow Fan
Material ASG30K1
Motor Type Transistor (8-poles)
Input Power W 94.8 - 94.8
Output Power W 40
Cool rpm 970
QLo
Heat rpm 1000
Cool rpm 1070
Lo
Heat rpm 1100
Cool rpm 1300
Me
Heat rpm 1330
Cool rpm 1530
Hi
Heat rpm 1560
Cool rpm 1570
Indoor Fan
Speed
SHi
Heat rpm 1570
Type Propeller Fan
Material PP
Motor Type DC Motor (8-poles)
Input Power W -
Output Power W 44 x 2
Cool rpm 610 - 650
Outdoor Fan
Speed Hi
Heat rpm 690 - 730
Moisture Removal L/h (Pt/h) 4.7 (9.9)
Cool m
3
/min (ft
3
/min) 12.20 (431)
QLo
Heat m
3
/min (ft
3
/min) 12.67 (447)
Cool m
3
/min (ft
3
/min) 13.66 (482)
Lo
Heat m
3
/min (ft
3
/min) 14.14 (499)
Cool m
3
/min (ft
3
/min) 17.03 (601)
Me
Heat m
3
/min (ft
3
/min) 18.01 (636)
Cool m
3
/min (ft
3
/min) 20.4 (720)
Hi
Heat m
3
/min (ft
3
/min) 20.9 (740)
Cool m
3
/min (ft
3
/min) 20.99 (741)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 21.55 (761)
Cool m
3
/min (ft
3
/min) 75.0 (2650)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 75.0 (2650)
Control Device Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (800)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 2.15k (75.9)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 1170 (46-3/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 900 (35-7/16)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 74 (163)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height different m (ft) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Piping
Length for Additional Gas m (ft) 10 (32.8)
