Unit CS-E24CKE CU-E24CKE
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 5/8”
L (liquid side) ; 1/4”
G (gas side) ; 5/8”
L (liquid side) ; 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.65 —
Power Cord Length
Number of core-wire
2.1 m
3 core wires × 1.5 mm
2
—
—
Dimensions Height inch (mm) 10 - 13/16 (275) 29 - 17/32 (750)
Width inch (mm) 39 - 9/32 (998) 34 - 7/16 (875)
Depth inch (mm) 8 - 9/32 (210) 13 - 19/32 (345)
Net Weight lb (kg) 26 (12) 140 (63.5)
Compressor Type — Hermetic Rotary
Motor Type — DC Brushless (4-pole)
Rated Output W — 1,500
Air Circulation Type Cross-flow Fan Propeller Fan
Material ASHT-18 P.P
Motor Type Transistor (8-poles) Transistor (8-poles)
Rate Output W 30 60
Fan Speed Lo (Cool/Heat) rpm 1,200 / 1,310 —
Me (Cool/Heat) rpm 1,390 / 1,500 —
Hi (Cool/Heat) rpm 1,580 / 1,690 830 / 810
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2/15 2/28
FPI 21 18
Size (W × H × L) mm 810 × 315 × 25.4 833.2
867.8
× 711.2 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (mL) — DAPHNE FV68S (650)
Refrigerant (R410A) kg (oz) — 1.85 (65.3)
Thermostat Electronic Control —
Protection Device Electronic Control Electronic Control
Length mm — Cooling; 393, Heating; 465
Capillary Tube Flow Rate l/min — Cooling; 16.8, Heating; 21.2
Inner Diameter mm — Cooling; 1.6, Heating; 2.2
Air Filter Material
Style
P.P.
Honeycomb
—
•
Specifications are subjected to change without notice for further improvement.
7
CS-E24CKE CU-E24CKE
