Panasonic CS-E7PKR - 17 Disassembly and Assembly Instructions; Cs-E7 Pk Cs-E9 Pk Cs-E12 Pk Cs-E15 Pk

142
WARNING
17. Disassembly and Assembly Instructions
High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with
repair work. Failure to heed this caution may result in electric shocks.
17.1 CS-E7PK CS-E9PK CS-E12PK CS-E15PK
17.1.1 Indoor Electronic Controllers, Cross Flow Fan and Indoor Fan Motor Removal
Procedures
17.1.1.1 To remove front grille
17.1.1.2 To remove power electronic controller
