Sensible Capacity Chart
#
##
#
CS-PW9CKE
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.88 2.18 0.78 2.69 2.09 0.84 2.50 2.01 0.90 2.27 1.91 0.97
19.0°C 2.90 0.85
19.5°C 3.16 2.28 0.79 2.95 2.19 0.85 2.75 2.11 0.91 2.50 2.01 0.98
22.0°C 3.44 2.37 0.81 3.22 2.28 0.87 2.99 2.20 0.93 2.72 2.09 1.00
#
##
#
CS-PW12CKE
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.71 2.81 1.01 3.47 2.70 1.08 3.22 2.59 1.16 2.93 2.46 1.25
19.0°C 3.74 1.10
19.5°C 4.07 2.94 1.03 3.81 2.83 1.10 3.54 2.72 1.18 3.22 2.59 1.27
22.0°C 4.44 3.05 1.05 4.15 2.94 1.12 3.86 2.83 1.20 3.51 2.70 1.30
TC - Total Cooling Capacity (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kW)
55
CS-PW9CKE / CU-PW9CKE / CS-PW12CKE / CU-PW12CKE
