Panasonic CS-S12VKV-2

26
Product specification
Indoor Unit
Outdoor Unit
Model
CS-S9VKV-2
CU-S9VKV-2
CS-S12VKV-2
CU-S12VKV-2
CS-S18VKV-2
CU-S18VKV-2
COOL COOL COOL
Single,
220 - 230V,
60Hz
Single,
220 - 230V,
60Hz
Single,
220 - 230V,
60Hz
Power/Current
[W]
650 930 1630
[A]
3,00 4,10 7,30
Power/Current
(For testing)
[W](MAX)
910 1150 2050
[A](MAX)
4,30 5,00 9,20
Refrigerant
[g]
R410A
710
R410A
880
R410A
1230
Cooling Capacity
[W]
2550 3520 5280
Cooling Capacity
(For testing)
[W](MAX)
3100 4000 6000
Noise Level
JIS C 9612
[<70 dB(A)]
[dB(A)]
40 42 48
Conditions 1m
Distance Max. cooling
47 47 49
Air Circulation
[m
3
/min.]
10,5 11,0 13,6
Product Weight
[kg]
9,5 9,5 9,5
24,5 28 35,5
Dimensions (H × W × D)
[mm]
289×918×194 289×918×194 289×918×194
542×780×289 542×780×289 626×825×320
• Standbypowerconsumption≤0,9W(whenswitchedOFFbyremotecontrol,exceptunderself-
protection control).
1. Standard piping length: 7,6 m.
2.Airltersareattached.
