8.2. Outline of installation
Installation works Installation parts Required tools
1. Installation of indoor, outdoor unit
●
Installation plate
●
A level gauge
1) Selet the best location........P.28
●
4 wooden screws
●
Philips screw driver
2) Indoor unit installation........P.29
●
4 anchor bolts
●
Electric drill hole coredrill (Ø70mm)
●
Side cutter or electrical pliers
2. Piping and drainage of indoor unit
●
Pipes: Gas side................... 1/2"
●
Flaring tools set
1) Prepare of piping........P.30 Gas side....................3/8" Specified torque wrenches
2) Connection of piping........P.31 Liquid side............. ...1/4" 18N.m.......Liquid side piping
For the right piping........P.31
●
Insulated drain hose 42N.m.......Gas side piping
For the left piping........P.32
●
Insulation materials 55N.m.......Gas side piping
Spanner.......Half union
3. In case of Embedded Piping
●
Pipes: Gas side................... 1/2"
●
Flaring tools set
For the embedded piping........P.34 Gas side....................3/8" Specified torque wrenches
Liquid side............. ...1/4" 18N.m.......Liquid side piping
●
Insulated drain hose 42N.m.......Gas side piping
●
Insulation materials 55N.m.......Gas side piping
Spanner.......Half union
4. Connecting piping and cable to the
outdoor unit
●
Additional drain hose
●
Specified torque wrenches
(Outer diameter......1.55mm) 18N.m.......Liquid side
1) Connecting the piping to the outdoor
unit........P.35
●
Connecting cable 42N.m.......Gas side
(5-core wire/1.5mm
2
) 55N.m.......Gas side
2) Connecting the cable........P.35 Locally approved cable
5. Air purging of the piping and indoor unit
●
Installation materials provided
●
Hexagonal wrench
1) Air purging........P.36
●
Tape provided
●
Gas leak detector
6.
Checking the drainage and connecting
the cable to indoor unit
●
Connecting cable
●
A glass of water
1) Checking the drainage........P.37 (5-core wire/1.5mm
2
)
●
Phillips screw driver
2) Connecting the inside/ outside
cable........P.38
●
Locally approved cable
3) Connect the cable to the indoor unit
........P.38
7. Test Running
●
Circuit breaker or time delay fuse
(consult an electrician)
1) Connect the power supply........P.39
2) Evaluation of the performance
........P.39
●
Operating instructions
●
Thermometer
27
CS-SA9CKP CU-SA9CKP5 / CS-SA12CKP CU-SA12CKP5
