Air
Circulation
Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber
20%
AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 29.3 123.0
Rated Output W 15 50
Fan Speed Low rpm 800 —
Medium rpm 940 —
High rpm 1,160 760
SuperHigh rpm 1,250 —
Heat
Exchanger
Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×24
FPI 19 14
Size (W × H × L) mm 610 × 315 × 25.4 756.0
719.5
× 609.6 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60 (330, 330)
Refrigerant (R410A) g(oz) — (A unit) 780 (27.5)
(B unit) 1,000 (35.3)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary
Tube
Length mm — 780, 645, 950
Flow Rate l/min — 16.2/13.5, 8.0
Inner Diameter mm — 1.8, 1.6, 1.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30/35 µF, 370 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 3.0 µF, 450 VAC
• Specifications are subject to change without notice for further improvement.
11
CS-V9BKPG CU-2V14BKP5G / CS-V9BKPG CU-2V18BKP5G / CS-V9BKP G CU-3V20BKP5G / CS-V7BKP G CU-2V19BKP5G / CS-V12BKPG
