Unit
One Unit (A)
CS-V12BKPG
One Unit (B)
CS-V7BKPG
CU-2V19BKP5G
Cooling Capacity kW
kcal/h
(A) 3.55
(A) 3,050
(B) 2.10
(B) 1,810
(A+B) 5.65
(A+B) 4,860
Moisture Removal l/h
Pint/h
(A) 2.1
4.4
(B) 1.4
3.0
(A+B) 3.1
6.6
Power Source Phase
V
Cycle
Single
230
50
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) 7.3 (260) 6.4 (230) —
Indoor Air (Me) m
3
/min (cfm) 8.7 (310) 7.4 (260) —
Indoor Air (Hi) m
3
/min (cfm) 10.2 (360) 8.5 (300) —
Indoor Air (SHi) m
3
/min (cfm) 10.5 (370) 9.4 (330) —
Noise Level dB (A) (A) High 39
Low 29
(B) High 33
Low 26
High 55
Power level
dB
(A) High 52 (B) High 46 High 70
Electrical Data Input W (A) 1,230 (B) 720 (A+B) 1,850
Running Current A (A) 5.5 (B) 3.2 (A+B) 8.3
EER W/W
(kcal/hW)
(A) 2.89
(2.48)
(B) 2.92
(2.51)
(A+B) 3.05
(2.63)
Starting Current A (A) 17.8 (B) 12.5 (A+B) 30.3
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”, 3/8”
L ; Half Union 1/4”, 1/4”
G ; 3-way valve 1/2”, 3/8”
L ; 3-way valve 1/4”, 1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 1/2”, 3/8”
L (liquid side) ; 1/4”, 1/4”
G (gas side) ; 1/2”, 3/8”
L (liquid side) ; 1/4”, 1/4”
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Dimensions Height inch (mm) 10 - 13/16 (275) 25 - 21/32 (651)
Width inch (mm) 31 - 15/32 (799) 35 - 3/16 (893)
Depth inch (mm) 8 - 9/32 (210) 13 - 19/32 (345)
Net Weight lb (kg) 20 (9.0) 146 (66)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W (A) 830 (B) 670 (A+B) 1,500
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W (A) 28.7 (B) 20.6 123.0
Rated Output W 15 50
Fan Speed Low rpm (A) 900 (B) 800 —
Medium rpm (A) 1,080 (B) 920 —
High rpm (A) 1,260 (B) 1,050 760
SuperHigh rpm (A) 1,300 (B) 1,140 —
12
CS-V9BKPG CU-2V14BKP5G / CS-V9BKPG CU-2V18BKP5G / CS-V9BKP G CU-3V20BKP5G / CS-V7BKP G CU-2V19BKP5G / CS-V12BKPG
