Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 15 2 × 24
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 723.5
744.2
× 504 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — FVC68D (330)
Refrigerant (R-410A) g (oz) — 1,060 (37.4)
Thermostat Electronic Control —
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 1276
Flow Rate l/min — 11.3
Inner Diameter mm — 1.7
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 35 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
•
Specifications are subject to change without notice for further improvement.
11
CS-V7CKP CU-V7CKP5 / CS-V9CKP CU-V9CKP5 / CS-V12CKP CU-V12CKP5
