26.2. PRINT PATTERN
INDOOR UNIT PRINTED CIRCUIT BOARD
TOP VIEW
93
CS-V9BKPG CU-2V14BKP5G / CS-V9BKPG CU-2V18BKP5G / CS-V9BKP G CU-3V20BKP5G / CS-V7BKP G CU-2V19BKP5G / CS-V12BKPG
