5.2 Outdoor Unit
5.2.1 CU-VU9SKQ CU-VU12SKQ
(18)
69.5 61.6
542
28939
570
22
(104.7)
67.6
780
85.5
155.2 34.3
60.5104.9
Space necessary
for installation
Anchor Bolt Pitch
320 × 570
1000 mm
100 mm
100 mm
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at
Liquid side
(High Pressure)
3-way valve at
Gas side
(Low Pressure)
320
R32
REFRIGERANT
5.2.2 CU-VU18SKQ
<Top View>
<Front View><Side View>
<Side View>
Anchor Bolt Pitch
330 × 540
Space necessary for
installation
100 mm
100 mm
1000 mm
Unit : mm
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
22 (124) (62.6)
330
619
167
97
69
(20)
62
32
540 160
824 68.7
37 299
R32
REFRIGERANT
