Unit CS-W9DKE CU-W9DKE
Dimensions Height inch (mm) 11 - 1/32 (280) 20 - 3/32 (510)
Width inch (mm) 31 - 15/32 (799) 25 - 19/32 (650)
Depth inch (mm) 7 - 7/32 (183) 9 - 1/16 (230)
Net Weight lb (kg) 20 (9.0) 64 (29)
Compressor Description — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 700
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASG20k1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 47 68
Rated Output W 15 30
Fan Speed Low rpm Cooling; 780 —
Heating; 840
Medium rpm Cooling; 980 —
Heating; 980
High rpm Cooling; 1,160 815
Heating; 1,310
SuperHigh rpm Cooling; 1,310 —
Heating; 1,310
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 15 2 × 23
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 597.7
585.7
× 483 × 36.4
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — FV50S (350)
Refrigerant (R-410A) g (oz) — 950 (33.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 475, Heating; 330
Flow Rate l/min — Cooling; 7.2, Heating; 10.7
Inner Diameter mm — Cooling; 1.2, Heating; 1.3
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440VAC 2.0 µF, 440VAC
•
Specifications are subject to change without notice for further improvement.
10
CS-W7DKE CU-W7DKE / CS-W9DKE CU-W9DKE / CS-W12DKE CU-W12DKE
