16.4.2. Replacement Parts List
<Model: CU-4E27CBPG>
Ref. No. Part Name & Description Q’ty Part No. Remarks
1 SWING COMPRESSOR 1 CW1266081
●
●●
●
2 SPRING 3 CW390208
3 NUT WITH WASHER 3 CWH56062
4 TERMINAL COVER 1 CW1262647
5 GUARD BUSH, POWER CORD 1 CW354120
6 RETAINER, OVER-LOAD RELAY 1 CW380620
7 SPRING HOLDER (1) 3 CW0960397
8 SPRING HOLDER (2) 3 CW390215
10 OVER-LOAD RELAY 1 CW1313747
●
●●
●
11 SOUND INSULATOR, COMP. (TOP) 1 CW1313754
12 SOUND INSULATOR, COMPRESSOR 1 CW1313761
13 SOUND INSULATOR, COMPRESSOR 1 CW1313778
14 CROSS-FIN CONDENSER ASS’Y 1 CW1313785
15 PUTTY 1 CW0640338
17 FOUR WAY VALVE 1 CW1305830
●
●●
●
18 DISCHARGE PIPE ASS’Y 1 CW1354399
19 CONNECTING PIPE 1 CW1354407
20 CONNECTING PIPE 1 CW1354414
21 SOLENOID VALVE ASS’Y 1 CW1313792
●
●●
●
22 CONNECTING PIPE 1 CW1354421
23 SUCTION LINE ASS’Y 1 CW1354438
24 PUTTY 1 CW1201589
26 SET PLATE, STOP VALVE 1 CW1313800
27 LIQUID RECEIVER 1 CW1313817
28 SET PLATE, STOP VALVE 1 CW1313824
30 STOP VALVE ASS’Y (LIQUID LINE) 1 CW1313831
●
●●
●
31 BRANCH PIPE 1 CW1354452
32 BODY, MOTORIZED EXP. VALVE 4 CW1318533
●
●●
●
33 UNION JOINT 4 CW0603214
34 STRAINER (FOR REF.) 4 CW1318230
35 STRAINER (FOR REF.) 1 CW0085296
36 PUTTY 4 CW1307014
37 SOUND ABSORBING PUTTY 1 CW1265374
39 STOP VALVE ASS’Y (GAS LINE) 1 CW1314252
●
●●
●
40 BRANCH PIPE 1 CW1354469
41 CONNECTING PIPE 4 CW1354476
42 UNION JOINT 4 CW257587
43 CONNECTING PIPE 1 CW1354483
44 FIXTURE UNION JOINT 4 CW1314269
45 FLARE NUT 3 CW0080347
46 BLIND CAP, FLARE NUT 3 CW1020937
47 CUSHION RUBBER 1 CW1314276
48 ACCUMULATOR ASS’Y 1 CW1314283
49 FLARE NUT 1 CW0080347
50 BLIND CAP, FLARE NUT 1 CW1020937
51 FLARE NUT 4 CW1198474
52 BLIND CAP, FLARE NUT 4 CW1020920
53 CAP, STOP VALVE 1 CW0454328
54 CAP, STOP VALVE 1 CW0079936
55 SOUND ABSORBING PUTTY 1 CW1128538
56 SOUND ABSORBING PUTTY 1 CW1040739
57 PUTTY 1 CW1314290
58 FITTING SPRING, THERMISTOR 8 CW380120
59 FIXTURE, THERMISTOR 4 CW1107384
60 FAN BLADE 1 CW1264302
61 LOCK NUT, FAN 1 CW847003
62 AIR DISCHARGE GRILLE 1 CW1314308
63 BELL MOUTH 1 CW1278882
64 GUARD NET 1 CW1314315
65 SWITCH BOX 1 CW1314322
66 CUSHION RUBBER 1 CW1307076
67 PRINTED CIRCUIT ASS’Y 1 CW1364295
●
●●
●
68 FUSE 1 CW0509002
69 VARISTOR 1 CW0608055
●
●●
●
70 WIRE HARNESS ASS’Y 1 CW1307083
71 HEAT SINK 1 CW1314339
●
●●
●
72 TERMINAL BLOCK 1 CW1364303
●
●●
●
73 PRINTED CIRCUIT ASS’Y (INVERTER) 1 CW1290402
●
●●
●
74 THERMISTOR 1 CW1302622
●
●●
●
75 RECTIFING STACK 1 CW628953
