Panasonic CU-3KS19NBU - Page 22

Wide tube service valve
dia.1/2" (12.70)
×1
Narrow tube service valve
dia.1/4" (6.35)
×4
Wide tube service valve
dia.3/8" (9.52)
×3
4-7/16
5-29/32 2-27/32 2-3/4
2-3/4
2-1/32 4-1/2
2-15/16
2-3/4 2-3/4
29-1/8(740)
23/32
1-13/16
35-7/16(900)
23-15/16 5-11/32
15/32
12-19/32(320)
13-19/32 14-17/32
11-17/32
ID:23/32
2-ID:15/16
1-3/8
2-15/16
2-1/16
2-13/32
Outdoor Unit CU-4KS24NBU
Unit: inch(mm)
(852-0-0010-20500-0)
22
