REF. NO. PART NAME & DESCRIPTION QTY. CU-E7NKE-3 CU-E9NKE-3 CU-E12NKE-3 REMARK
1 CHASSIS COMPLETE 1 CWD50K2073 ← ←
2 SOUND PROOF MATERIAL 1 CWG302314 ← ←
3 FAN MOTOR BRACKET 1 CWD541089 ← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ←
5 FAN MOTOR 1 CWA951720 CWA951721 CWA951699 o
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
7 PROPELLER FAN ASSY 1 CWH03K1010 ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ←
9 COMPRESSOR 1 5RS092XCD21 5RS102XBC21 ← o
10 ANTI - VIBRATION BUSHING 3 CWH50077 ← ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ← ←
12 CONDENSER 1 CWB32C2985 CWB32C2448 ←
13 TUBE ASSY CO. (CAP./CHK VALVE) 1 CWT01C5305 CWT01C4850 CWT01C4851
14 DISCHARGE MUFFLER 1 CWB121010 ← ←
15 HOLDER COUPLING 1 CWH351023 ← ←
16 2-WAYS VALVE (LIQUID) 1 CWB021559 CWB021457 ← o
17 3-WAY VALVE (GAS) 1 CWB011374 ← ← o
19 REACTOR 1 G0C193J00002 ← G0C193J00004 o
20 TERMINAL COVER 1 CWH171039A ← ←
21 NUT - TERMINAL COVER 1 CWH7080300J ← ←
22 SOUND PROOF BOARD 1 CWH151172 ← ←
23A SOUND PROOF MATERIAL 1 CWG302316 ← ←
23B SOUND PROOF MATERIAL 1 CWG302317 ← ←
23C SOUND PROOF MATERIAL 1 CWG302315 ← ←
24 SENSOR CO-COMP TEMP 1 CWA50C2205 ← ← o
25 CONTROL BOARD COVER-TOP 1 CWH131264 ← ←
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6654R CWA73C6656R CWA73C6658R o
27 TERMINAL BOARD ASSY 1 CWA28K1110J ← ← o
28 CABINET SIDE PLATE CO. (RIGHT) 1 CWE04C1116 ← ←
29 SENSOR CO-AIR TEMP AND PIPE TEMP 1 CWA50C2764 ← ← o
30 CABINET SIDE PLATE (LEFT) 1 CWE041248A ← ←
31 CABINET FRONT PLATE CO. 1 CWE06C1039 CWE06C1136 ←
32 CABINET TOP PLATE 1 CWE031014A ← ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ← ←
34 CONTROL BOARD COVER CO. 1 CWH13C1211 ← ←
35 HANDLE 1 CWE161010 ← ←
38 4-WAYS VALVE 1 CWB001037J ← ← o
39 V-COIL COMPLETE 1 CWA43C2431 ← ← o
40 WIRE NET 1 CWD041111A ← ←
47 CRANKCASE HEATER 1 CWA341044 ← ←
50 BAG-COMPLETE 1 CWG87C900 ← ←
51 BAG 1 CWG861078 ← ←
52 BASE BOARD-COMPLETE 1 CWG62C1095 ← ←
53 SHOCK ABSORBER 1 CWG712969 ← ←
54 SHOCK ABSORBER 1 CWG712970 ← ←
55 C.C. CASE 1 CWG568357 ← ←
(NOTE)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
 “O” marked parts are recommended to be kept in stock.
