88
<Model: CU-E24GKR, CU-E28GKR>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SFBZ0706 - 00
REF. NO. DESCRIPTION & NAME QTY. CU-E24GKR CU-E28GKR
1 CHASSY ASS’Y 1 CWD52K1177 ←
2 COMPRESSOR (DC 280V) 1 5KD240XAA21 ←
3 ANTI - VIBRATION BUSHING 3 CWH50055 ←
4 NUT - COMPRESSOR MOUNT 3 CWH561049 ←
5 PACKING 3 CWB811017 ←
6 CONDENSER 1 CWB32C1996 CWB32C2164
7 SOUND PROOF MATERIAL 1 CWG302462 ←
8 SOUND PROOF MATERIAL 1 CWG302463 ←
9 SOUND PROOF BOARD 1 CWH151075 ←
10 FAN MOTOR BRACKET 1 CWD54K1034 ←
11 SCREW - FAN MOTOR BRACKET 2 CWH551040J ←
12 FAN MOTOR, AC 80W SINGLE 1 CWA951510 ←
13 SCREW - FAN MOTOR MOUNT 4 CWH551040J ←
14 PROPELLER FAN 1 CWH001019 ←
15 NUT - PROPELLER FAN 1 CWH561038J ←
16 4-WAY VALVE 1 CWB001026J ←
17 RECEIVER 1 CWB14030 CWB14017
18 DISCHARGE MUFFLER 1 CWB121013 ←
19 STRAINER 2 CWB111032 ←
20 2-WAY VALVE (LIQUID) 1 CWB021330 ←
21 TUBE ASSY (CAP.TUBE) 1 CWT07K1350 CWT07K1321
22 3-WAY VALVE (GAS) 1 CWB011251 ←
23 EXPANSION VALVE 1 CWB051016J CWB051018J
24 SENSOR COMPLETE 1 CWA50C2381 ←
25 SENSOR - COMP.DISCHARGE 1 CWA50C2214 ←
26 V-COIL COMPLETE 1 CWA43C2169J ←
27 V-COIL COMPLETE FOR EXP. VALVE 1 CWA43C2058J CWA43C2128J
28 TERMINAL COVER 1 CWH171039A ←
29 NUT - TERMINAL COVER 1 CWH7080300J ←
30 CONTROL BOARD CASING 1 CWH10K1046 ←
31 CAPACITOR - F.M (3.5μF/440V) 1 DS441355NPQA ←
32 TERMINAL BOARD ASSY 1 CWA28K1179 ←
33 TERMINAL BOARD ASSY 1 CWA28K1076J ←
34 CABINET REAR PLATE - CO. 1 CWE02C1037 ←
35 CABINET SIDE PLATE ASSY 1 CWE04K1019A ←
36 HANDLE 3 CWE161008 ←
37 CABINET FRONT PLATE 1 CWE061118A ←
38 DISCHARGE GRILLE 1 CWE201073 ←
39 CABINET FRONT PLATE CO. 1 CWE06C1086 ←
40 PIPE COVER (FRONT) 1 CWD601074A ←
41 PIPE COVER (BACK) 1 CWD601075A ←
42 WIRE NET 1 CWD041102A ←
43 CABINET TOP PLATE ASSY 1 CWE03C1040 ←
44 ELECTRONIC CONTROLLER 1 CWA745001 CWA745002
45 ELECTRONIC CONT. - NOISE FILTER 1 CWA744495 ←
46 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2819R CWA73C2820R
47 SENSOR CO (COMP.TOP) 1 CWA50C2185 ←
48 REACTOR 2 G0C452J00002 ←
49 DRAIN HOSE 6 CWH5850080 ←
50 PACKING - L.TUBE 1 CWB811010 ←
51 WIRING COVER AND BAND 1 CWH82C1105 ←
52 OPERATION INSTRUCTIONS 1 CWF565729 ←
53 INSTALLATION INSTRUCTIONS 1 CWF613287 ←
