Soft Dry Operation Time Diagram
a
b
c
def
g
h
i
j
k
l
m
n
opq
rs
tuv
Basic time
Compressor
Indoor Fan
Outdoor Fan
Operation LED
4-way valve
1’ 1’
1’6’
6’
6’ 6’
4’
1’
Cooling ON
Cooling OFF
Soft Dry ON
Soft Dry OFF
1.5°C
1.0°C
SLoSLo SLo SLoSLo SLo SLo SLoSLo SLo SLo SLo
Indoor
Heat Exchanger
Temp.
16°C
2°C
6’
Intake Air
Temperature
Set Temp.
1’
<Description of operation>
a – c : Cooling Operation
c – p : Soft Dry Operation
e – f : Soft Dry OFF
j – l : 60 sec. Forced Operation
q – t : Anti Freezing Control
Soft Dry operation
- - - - -
Cooling operation
Operation
Stop
