Model Cooling capacities are based conditions
CS-W34BD2P
●
Indoor temp. 27°C D.B. 19°C W.B.
●
Outdoor temp. 35°C D.B.
●
Standard air volume 33 m
3
/min
●
External Static Pressure (147Pa)
Cooling capacity
10.0kW
Entering Temperature Air Entering Condenser (°C D.B.)
Air 25°C 30°C 35°C 40°C 43°C
Temperature TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 10.4 6.97 3.47 10.0 6.90 3.67 9.41 6.68 3.94 8.70 6.35 4.25 8.09 6.07 4.42
23 19 11.0 5.83 3.68 10.7 5.86 3.89 10.1 5.76 4.18 9.42 5.56 4.46 8.83 5.39 4.64
22 12.0 4.92 3.97 11.7 5.02 4.20 11.1 5.02 4.52 10.4 4.90 4.82 9.80 4.81 4.87
17 10.3 8.13 3.45 9.90 8.01 3.67 9.32 7.73 3.94 8.64 7.34 4.22 8.10 7.05 4.40
25 19 11.0 7.15 3.68 10.6 7.12 3.90 10.1 6.94 4.20 9.36 6.65 4.47 8.82 6.44 4.66
22 12.0 5.88 3.97 11.6 5.93 4.21 11.1 5.86 4.53 9.90 5.46 4.75 9.8 5.58 4.79
17 10.2 9.70 3.44 9.80 9.48 3.66 9.22 9.22 3.94 8.57 8.57 4.18 8.11 8.11 4.37
27 19 11.0 8.38 3.68 10.6 8.27 3.92 10.0 8.00 4.21 9.30 7.63 4.47 8.80 7.39 4.67
22 12.0 6.83 3.97 11.6 6.84 4.23 11.0 6.70 4.55 9.42 5.94 4.83 9.80 6.34 4.86
17 10.1 9.60 3.42 9.80 9.48 3.63 9.25 9.25 3.88 8.64 8.64 4.11 8.21 8.21 4.29
29 19 11.0 10.1 3.65 10.6 10.0 3.88 10.0 9.60 4.15 9.37 9.19 4.39 8.91 8.91 4.58
22 11.9 8.00 4.03 11.5 7.96 4.27 10.9 7.76 4.57 9.90 7.23 4.84 9.70 7.31 4.96
17 10.1 9.60 3.41 9.80 9.48 3.61 9.27 9.27 3.84 8.69 8.69 4.06 8.28 8.28 4.23
32 19 11.0 10.4 3.64 10.6 10.3 3.86 10.0 10.0 4.10 9.42 9.42 4.34 8.98 8.98 4.52
22 11.9 9.90 4.06 11.5 9.80 4.30 10.9 9.48 4.58 10.2 9.10 4.84 9.70 8.86 5.05
Model Cooling capacities are based conditions
CS-W43BD2P
●
Indoor temp. 27°C D.B. 19°C W.B.
●
Outdoor temp. 35°C D.B.
●
Standard air volume 36 m
3
/min
●
External Static Pressure (147Pa)
Cooling capacity
12.5kW
Entering Temperature Air Entering Condenser (°C D.B.)
Air 25°C 30°C 35°C 40°C 43°C
Temperature TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 13.0 8.72 4.28 12.5 2.96 4.53 11.8 8.35 4.87 10.9 7.94 5.25 10.1 7.58 5.46
23 19 13.7 7.28 4.54 4.60 2.50 4.80 12.6 7.20 5.16 11.8 6.95 5.57 11.0 6.74 5.73
22 15.0 6.15 4.91 5.00 2.11 5.19 13.9 6.27 5.58 13.0 6.13 6.01 12.3 6.01 6.13
17 12.9 10.2 4.27 4.30 3.50 4.53 11.6 9.70 4.87 10.8 9.18 5.23 10.1 8.81 5.43
25 19 13.8 8.94 4.54 4.50 3.04 4.82 12.6 8.67 5.18 11.7 8.31 5.56 11.0 8.05 5.75
22 15.0 7.35 4.90 4.90 2.50 5.20 13.8 7.33 5.60 12.4 6.82 6.01 12.2 6.97 6.09
17 12.7 12.1 4.25 4.20 4.10 4.53 11.5 11.5 4.87 10.7 10.7 5.20 10.1 10.1 5.40
27 19 13.8 10.5 4.54 13.3 3.5 4.84 12.5 10.0 5.20 11.6 9.53 5.56 11.0 9.24 5.77
22 15.0 8.54 4.90 5.00 2.89 5.22 13.7 8.37 5.62 11.8 7.42 6.00 12.2 7.92 6.12
17 12.7 12.0 4.22 4.20 4.10 4.48 11.6 11.6 4.79 10.8 10.8 5.11 10.3 10.3 5.30
29 19 13.7 12.6 4.51 4.50 4.20 4.79 12.5 12.0 5.12 11.7 11.5 5.47 11.1 11.1 5.66
22 14.9 10.0 4.97 5.00 3.40 5.28 13.7 9.70 5.64 12.4 9.03 6.02 12.2 9.14 6.19
17 12.7 12.0 4.21 4.10 4.10 4.46 11.6 11.6 4.74 10.9 10.9 5.06 10.3 10.3 5.23
32 19 13.7 13.0 4.50 4.60 4.40 4.76 12.6 12.6 5.07 11.8 11.8 5.40 11.2 11.2 5.59
22 14.9 12.4 5.02 14.4 4.30 5.31 13.6 11.9 5.66 12.8 11.4 6.03 12.2 11.1 6.24
58
