16 Replacement Parts List (Indoor Unit)
16.1. CS-W7DKE CS-W9DKE CS-W12DKE
REF. NO. PART NAME & DESCRIPTION QTY. CS-W7DKE CS-W9DKE CS-W12DKE REMARKS
1 CHASSY COMPLETE 1 CWD50C1377
← ←
2 FAN MOTOR 1 CWA921181
← ←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1031
← ←
4 BEARING ASS’Y 1 CWH64K007
← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
6 EVAPORATOR 1 CWB30C1597
←
CWB30C1583
7 FLARE NUT 1 CWT25086(1/4”)
← ←
8 FLARE NUT 1 CWT25087 (3/8”)
←
CWT25096 (1/2”)
9 HOLDER SENSOR 1 CWH32143
← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2366
← ←
11 VERTICAL VANE 9 CWE241150
← ←
12 CONNECTING BAR 1 CWE261066
← ←
13 CONNECTING BAR 1 CWE261070
← ←
14 AIR SWING MOTOR 1 CWA98260
← ←
0
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
← ←
16 CAP - DRAIN TRAY 1 CWH521096
← ←
17 HORIZONTAL VANE 1 CWE241173
← ←
18 BACK COVER CHASSIS 1 CWD932454
← ←
19 CONTROL BOARD CASING 1 CWH102259
← ←
20 TERMINAL BOARD COMPLETE 1 CWA28C2074
←
CWA28C2071 0
21 POWER SUPPLY CORD 1 CWA20C2159
← ←
22 ELECTRONIC CONTROLLER - MAIN 1 CWA743658 CWA743656 CWA743558 0
24 SENSOR COMPLETE 1 CWA50C2122
← ←
0
25 CONTROL BOARD FRONT COVER 1 CWH131195
← ←
26 INDICATOR COMPLETE 1 CWE39C1115
← ←
0
27 INDICATOR HOLDER 1 CWD932429
← ←
28 INDICATOR HOLDER 1 CWD932430
← ←
29 CONTROL BOARD TOP COVER 1 CWH131207
← ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2604
← ←
0
31 FRONT GRILLE COMPLETE 1 CWE11C3125
← ←
0
32 INTAKE GRILLE 1 CWE22C1154
← ←
33 GRILLE DOOR 1 CWE141073
← ←
34 AIR FILTER 2 CWD001144
← ←
35 SCREW - FRONT GRILLE 2 XTT4+16C
← ←
36 CAP - FRONT GRILLE 2 CWH521109
← ←
37 DRAIN HOSE 1 CWH851063
← ←
38 INSTALLATION PLATE 1 CWH361067
← ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
← ←
40 FULCRUM 1 CWH621046
← ←
41 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675
← ←
0
42 CASING - IONIZER 1 CWD932464
← ←
43 CASING - IONIZER 1 CWD932431
← ←
44 ION GENERATOR 1 CWH94C0001
← ←
45 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013
← ←
46 ELECTRONIC CONTROLLER SUPERSONIC 1 CWA743874
← ←
0
47 SUPER ALLERU BUSTER FILTER 1 CWD00C1133
← ←
48 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026
← ←
49 FRAME FR AIR FILTER SUPERSONIC 1 CWD011027
← ←
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
