18 Replacement Parts List (Outdoor Unit)
18.1. CU-W7DKE CU-W9DKE
REF. NO. PART NAME & DESCRIPTION QTY. CU-W7DKE CU-W9DKE REMARKS
1 CHASSY ASS’Y 1 CWD50K2112
←
2 SOUND PROOF MATERIAL 1 CWG302255
←
3 FAN MOTOR BRACKET 1 CWD541073
←
4 SCREW - FAN MOTOR BRACKET 2 CWH551060
←
5 FAN MOTOR 1 CWA951388
←
0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
←
7 PROPELLER FAN ASS’Y 1 CWH03K1020
←
8 NUT - PROPELLER FAN 1 CWH56053
←
9 COMPRESSOR 1 5RS084DAB21 5PS102DAH21 0
10 ANTI - VIBRATION BUSHING 3 CWH50077
←
11 NUT - COMPRESSOR MOUNT 3 CWH56000
←
12 CONDENSER 1 CWB32C1498
←
13 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C3239 CWT01C3266
14 STRAINER 1 CWB11025
←
15 HOLDER COUPLING ASS’Y 1 CWH351047
←
16 2-WAY VALVE (LIQUID) 1 CWB021236
←
0
17 3-WAY VALVE (GAS) 1 CWB011278
←
0
18 TERMINAL COVER 1 CWH171011
←
19 NUT - TERMINAL COVER 1 CWH7080300
←
20 SOUND PROOF BOARD 1 CWH151074
←
22 TERMINAL BOARD ASS’Y 1 CWA28K1021
←
23 CAPACITOR - COMPRESSOR 1 CWA312074
(20µF, 400VAC)
DS371306CPND
(30µF, 370VAC)
0
24 HOLDER CAPACITOR 1 CWH301038 CWH301035
25 CAPACITOR - FAN MOTOR 1 DS441205NPQA
(2.0µF, 440VAC)
←
0
26 CABINET SIDE PLATE (L) 1 CWE041110A
←
27 CABINET SIDE PLATE (R) 1 CWE04C1050
←
28 CABINET FRONT PLATE 1 CWE06K1052 CWE06K1051
29 WIRE NET 1 CWD041057A
←
30 CABINET TOP PLATE 1 CWE031041A
←
32 CONTROL BOARD COVER 1 CWH131193
←
34 OPERATION INSTRUCTIONS (ENG., ESP., ITA., NED., POR.,
GRE., BUL.)
1 CWF564484
←
35 INSTALLATION INSTRUCTIONS (ENG., FRA., ESP. & DEU.) 1 CWF612663
←
36 OVERLOAD PROTECTOR 1 CWA121066 CWA121213 0
37 4-WAY VALVE 1 CWB001011
←
38 V-COIL COMPLETE 1 CWA43C2174
←
39 ELECTRO MAGNETIC SWITCH 1 CWA00059
←
40 ELECTROLYTIC CAPACITOR 1 CWA32C1003
←
42 TEMPERATURE RELAY 1 CWA14C1009
←
43 L.TUBE 1 CWH5850080
←
44 PACKING - L.TUBE 1 CWB81012
←
45 HOLDER O.L.P. 1 CWH7041200
←
46 OPERATING INSTRUCTION (FRA., DEU., SWE., NOR) 1 CWF564485
←
47 INSTALLATION INSTRUCTIONS (ITA., NED., POR. & GRE.) 1 CWF612664
←
48 INSTALLATION INSTRUCTIONS (BUL.) 1 CWF612679
←
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
