18.2. CU-W12DKE
REF. NO. PART NAME & DESCRIPTION QTY. CU-W12DKE REMARKS
1 CHASSY ASS’Y 1 CWD50K2073
2 SOUND PROOF MATERIAL 1 CWG302088
3 FAN MOTOR BRACKET 1 CWD541030
4 SCREW - FAN MOTOR BRACKET 2 CWH551059
5 FAN MOTOR 1 CWA951117 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
7 PROPELLER FAN ASS’Y 1 CWH03K1006
8 NUT - PROPELLER FAN 1 CWH56053
9 COMPRESSOR 1 5PS132DAG21 0
10 ANTI - VIBRATION BUSHING 3 CWH50077
11 NUT - COMPRESSOR MOUNT 3 CWH4582065
12 CONDENSER 1 CWB32C1563
13 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C3363
14 STRAINER 1 CWB11025
15 HOLDER COUPLING ASS’Y 1 CWH351023
16 2-WAY VALVE (LIQUID) 1 CWB021057 0
17 3-WAY VALVE (GAS) 1 CWB011062 0
18 TERMINAL COVER 1 CWH171011
19 NUT - TERMINAL COVER 1 CWH7080300
20 SOUND PROOF BOARD 1 CWH151023
21 CONTROL BOARD CASING 1 CWH102102
22 TERMINAL BOARD ASS’Y 1 CWA28C2170
23 CAPACITOR - COMPRESSOR 1 DS371256CPNA
(25µF, 370VAC)
0
24 HOLDER CAPACITOR 1 CWH30057
25 CAPACITOR - FAN MOTOR 1 DS441205NPQA
(2.0µF, 440VAC)
0
26 CABINET SIDE PLATE (L) 1 CWE041031A
27 CABINET SIDE PLATE (R) 1 CWE041037A
28 CABINET FRONT PLATE 1 CWE06K1034
29 WIRE NET 1 CWD04C1009
30 CABINET TOP PLATE 1 CWE031014A
31 PLATE - C. B. COVER 1 CWH131088
32 CONTROL BOARD COVER 1 CWH131092
33 HANDLE 1 CWE161010
34 OPERATION INSTRUCTIONS (ENG., ESP., ITA., NED., POR., GRE.,
BUL.)
1 CWF564484
35 INSTALLATION INSTRUCTIONS (ENG., FRA., ESP. & DEU.) 1 CWF612663
36 OVERLOAD PROTECTOR 1 CWA121214 0
37 4-WAY VALVE 1 CWB001011
38 V-COIL COMPLETE 1 CWA43C2069
39 ELECTRO MAGNETIC SWITCH 1 CWA00059
40 ELECTROLYTIC CAPACITOR 1 CWA32C067
41 ELECTRO MAGNETIC SWITCH 1 K6A2C7A00002
42 TEMPERATURE RELAY 1 CWA14C1009
43 L.TUBE 1 CWH5850080
44 PACKING - L.TUBE 1 CWB81012
45 OPERATING INSTRUCTION (FRA., DEU., SWE., NOR) 1 CWF564485
46 INSTALLATION INSTRUCTIONS (ITA., NED., POR., & GRE.) 1 CWF612664
47 INSTALLATION INSTRUCTIONS (BUL.) 1 CWF612679
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
