Panasonic CY-PAD1003N

6 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
•
• •
• Order intake period is basically six months after the first
shipment.
5. “T” marks in remarks colum are indicated supply parts of
PTW.
Ref. No. Part No. Part Name & Description Remarks
[11-06A15-32-G] Main Block
IC´s AND TRANSISTORs
QP16 07-07815-00 IC T
QP17 07-07915-00 IC T
U1 07-00072-01 IC T
U2 07-00072-01 IC T
U3 07-00072-01 IC T
U4 07-00072-01 IC T
UP1 07-00494-00 IC T
Q2 08-05401-00 Transistor T
Q5 08-00034-00 Transistor T
Q6 08-00034-00 Transistor T
Q11 08-03421-00 Transistor T
Q12 08-05551-85 Transistor T
Q13 09-00114-01 Transistor T
Q13A 09-00114-00 Transistor T
Q14 08-05401-85 Transistor T
Q15 08-05401-85 Transistor T
Q16 08-03904-85 Transistor T
Q19 08-03421-00 Transistor T
QF1 08-10667-01 Transistor T
QP1 08-05551-00 Transistor T
QP2 08-05401-00 Transistor T
QP3 08-05551-00 Transistor T
QP4 08-05401-00 Transistor T
QP5 08-05401-00 Transistor T
QP6 08-50N06-00 Transistor T
QP7 08-50N06-00 Transistor T
QP8 08-50N06-00 Transistor T
QP9 08-50N06-00 Transistor T
QP10 08-50N06-00 Transistor T
QP11 08-50N06-00 Transistor T
QP12 08-01358-00 Transistor T
QP13 08-05551-00 Transistor T
QP14 08-05551-00 Transistor T
QP15 08-05551-00 Transistor T
U99 08-05551-00 Transistor T
DIODEs
D5 09-14148-85 Diode T
D15 09-20130-01 Zener Diode T
Ref. No. Part No. Part Name & Description Remarks
D17 09-14148-85 Diode T
D18 09-20056-03 Zener Diode T
D22 09-00240-86 Zener Diode T
D23 09-14148-85 Diode T
DA1 09-14148-85 Diode T
DA2 09-14148-85 Diode T
DA10 09-14148-01 Diode T
DA20 09-14148-85 Diode T
DP1 09-14148-01 Diode T
DP4 09-14148-01 Diode T
DP5 09-14004-00 Diode T
DP6 09-14148-01 Diode T
DP7 09-14148-01 Diode T
DP8 09-14148-01 Diode T
DP9 09-14148-01 Diode T
DP10 09-14148-01 Diode T
DP11 09-20A20-00 Diode T
DP12 09-20C20-00 Diode T
DP13 09-00154-00 Diode T
DP14 09-00154-00 Diode T
DP15 09-00154-00 Diode T
DP16 09-00154-00 Diode T
DP17 09-15401-01 Diode T
DP20 09-14148-01 Diode T
DP21 09-14148-01 Diode T
Z4 09-20056-85 Zener Diode T
ZA1 09-20120-03 Zener Diode T
ZA2 09-20120-03 Zener Diode T
ZD2 09-20390-03 Zener Diode T
ZD3 09-20390-03 Zener Diode T
ZD4 09-00047-00 Zener Diode T
ZF1 09-00075-00 Zener Diode T
LED 19-00329-00 LED T
PHOTOCOUPLERs
P1 07-00817-02 Photocoupler T
P2 07-00817-02 Photocoupler T
CAPACITORs
C1 04-21000-05 100PF 50WV T
C2 02-21001-46 10µF 50WV T
C3 04-21000-05 100PF 50WV T
C4 02-21001-46 10µF 50WV T
C5 02-21001-46 10µF 50WV T
C6 02-21001-46 10µF 50WV T
C7 02-21001-46 10µF 50WV T
C8 02-21001-46 10µF 50WV T
C9 04-21000-05 100PF 50WV T
C10 04-21000-05 100PF 50WV T
C11 02-21001-46 10µF 50WV T
C12 03-21030-60 0.01µF 63WV T
C13 03-21030-60 0.01µF 63WV T
C14 03-26830-06 0.068µF 63WV T
C14A 03-21030-60 0.01µF 63WV T
C15 03-26830-06 0.068µF 63WV T
C15A 03-21040-07 0.1µF 63WV T
C17 04-21500-05 150PF 100WV T
C18 03-24740-03 0.47µF 63WV T
C19 03-21040-07 0.1µF 63WV T
C20 03-24730-06 0.047µF 63WV T
C21 03-21040-07 0.1µF 63WV T
C25 03-21040-85 0.1µF 50WV T
C31 03-22240-05 0.22µF 100WV T
C32 03-22240-05 0.22µF 100WV T
C33 03-22240-05 0.22µF 100WV T
C38 02-24702-61 470µF 80WV T
C39 02-24702-61 470µF 80WV T
C51 06-00474-02 0.47µF 400WV T
C51A 02-22201-45 22µF 50WV T
C51B 06-00684-01 0.68µF 250WV T
C51C 03-21030-60 0.01µF 63WV T
C55 02-21002-85 100µF 16WV T
4
CY-PAD1003N
