Panasonic DH-3VS1 - PARTS IDENTIFICATION

EN4
English
ACCESSORIES
Packing: Included Items:
DH-3VS1 /
DH-3VP1 /
DH-4VS1 /
DH-4VP1 /
DH-6VS1
DH-3VL1 /
DH-4VL1 /
DH-3WL1
○ -
Shower Head Packing Shower Head (1 set)
- ○
Shower Head Packing Shower Head (1 set)
○ -
Shower Hanger Packing
Shower Hose
(1 set)
Rail Holder
(2 sets)
Shower Hanger
Ass’y (1 set)
- ○
Shower Hanger Packing Shower Hose (1 set) Shower Hanger Ass’y (1 set)
OFF
MA
C
LE
FILT
E
R
ANING
OFF
MA
CLE
FILTER
ANING
- Place Rubber Packing between Filter Body Assembly and Main Body.
- Tighten the Nut by hand firmly.
- Make sure the Filter Body Assembly is in straight line with the unit inlet.
- Make sure no water leakage.
DH940E-4UD10
Filter Body Assembly Caution Sheet
WARNING /
- Be sure to install the Home Shower Unit on the wall in vertical position
with the inlet and outlet water connection pointing downward.
-
‘Filter Body Assembly’ Installation
-
-
-
-
Inlet Side Thread End (Main Body)
Rubber Packing
Filter Body
Assembly
O
P
E
N
C
L
O
S
E
FILTER
CLEANING
OFF
MAX
* Model differs according to
Home Shower Unit.
O
P
E
N
C
L
O
S
E
FILTER
CLEANING
WATER
VOLUME
OFFMAX
OFF
MAX
HILO
O
P
E
N
C
L
O
S
E
FILTER
CLEANING
- Make sure to install the Filter Body Assembly to the Home Shower Unit.
- Never install Filter Body Assembly at the outlet, inlet water cannot be
filtered and allows foreign particles to enter the Unit. It will cause Heater
Unit and Shower Head to clog up.
CAUTION /
-
-
○ ○
Filter Body Packing
Filter Body
Assembly (1 set)
Rubber Packing
(1 pc)
Filter Body Assembly
Caution Sheet (1 pc)
○ -
Sliding Rail Sliding Rail (1 pc)
x 8
x 2
x 8
○ -
Installation Packing Wall Plug (8 pcs)
Rubber Packing
(2 pcs)
Screws (8 pcs)
x 6
x 2
x 6
- ○
Installation Packing Wall Plug (6 pcs)
Rubber Packing
(2 pcs)
Screws (6 pcs)
○ ○
Installation Template Installation Template (1 pc)
