Panasonic DMP-BD Series - Page 2

2
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precaution -------------------------------------------------3
1.1. General guidelines-----------------------------------------3
1.2. Caution for fuse replacement ---------------------------3
2Warning--------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatic Sensitive (ES) Devices---------------4
2.2. Precaution of Laser Diode -------------------------------5
2.3. Service caution based on legal restrictions----------6
3 Service Navigation------------------------------------------------7
3.1. Service Information ----------------------------------------7
4 Specifications ------------------------------------------------------8
5 Location of Controls and Components--------------------9
6 Operation Instructions ----------------------------------------10
6.1. Taking out the Disc from BD Drive Unit when
the Disc cannot be ejected by OPEN/CLOSE
button--------------------------------------------------------10
7 Service Mode----------------------------------------------------- 11
7.1. Self-Diagnosis and Special Mode Setting---------- 11
8 Service Fixture & Tools --------------------------------------- 19
9 Disassembly and Assembly Instructions--------------- 20
9.1. Unit-----------------------------------------------------------20
9.2. BD Drive---------------------------------------------------- 24
10 Measurements and Adjustments --------------------------29
10.1. Service Positions----------------------------------------- 29
