Ref. No. Part No. Part Name & Description Pcs Remarks
19 RHD30113-1K SCREW 2 EPK,ECK,EGK
21 RKM0552-S TOP CASE 1
EBS,EPS,EBLS,ECS,EGS
21 RKM0552-K TOP CASE 1
EPK,ECK,EGK
23 RMC0625 TUNER END 2
26 XYN3+J8FJ SCREW 1
27 RMQ1555 GASKET 2
28 VEP71109A POWER SUPPLY P.C.B. 1 (RTL)
29 VEP07A91C TUNER P.C.B. 1 (RTL)EBS
29 VEP07A91D TUNER P.C.B. 1 (RTL)EPK,EPS,EBLS
29 VEP07A91B TUNER P.C.B. 1 (RTL)ECK,ECS
29 VEP07A91A TUNER P.C.B. 1 (RTL)EGK,EGS
30 XSN3+4FJ SCREW 1
31 RMQ1551 GASKET A 1
32 VMX1336 MINI CARD SPACER 1
33 RQLS0375 CAUTION LABEL 1
A1 EUR7659Y50 REMOTE CONTROL ASS’Y 1 EBS,EBLS
A1 EUR7659Y40 REMOTE CONTROL ASS’Y 1 EPK,EPS,ECK,ECS,EGK,EGS
A1-1 UR76EC5903A BATTERY COVER 1
A2 K2CT3CA00004 AC CORD 1
EBS,EBLS
A2 RJA0043-1C AC CORD 1
EPK,EPS,ECK,ECS,EGK,EGS
A3 K2KA6BA00003 AV CORD 1
A4 K1TWACC00001 RF COAXIAL CABLE 2
A5 K1TWACA00001 RF CABLE 1 EBS,EBLS
A7 RPQD0003 PAD (C) 1
A8 RPQFD0001 ACCESSORY BOX 1
A9 RPFD0005 POLYETHYLENE BAG(F.B) 1 ECK,ECS,EGK,EGS
A10 RQCA1474 SET UP GUIDE 1 EBS,EBLS
A11 RQCA1546 REFERENCE GUIDE 1 EBS,EBLS
A12 RQCC2704 DVD MEDIA SHEET 1
A13 RQT8318-D OPERATING INSTRUCTIONS 1
(IA)ECK,ECS,EGK,EGS
A13 RQT8319-E OPERATING INSTRUCTIONS 1
(IB)ECK,ECS
A13 RQT8320-B OPERATING INSTRUCTIONS 1
(IC)EBS,EBLS
A13 RQT8321-R OPERATING INSTRUCTIONS 1
(ID)EPK,EPS
A13 RQT8389-H OPERATING INSTRUCTIONS 1
(IE)ECK,ECS
A13 RQT8390-1J OPERATING INSTRUCTIONS 1
(IF)ECK,ECS,EGK,EGS
PC1 RPG7913 PACKING CASE 1 EBS
PC1 RPG7914 PACKING CASE 1 EBLS
PC1 RPG7915 PACKING CASE 1 EPS
PC1 RPG8016 PACKING CASE 1 EPK
PC1 RPG7912 PACKING CASE 1 ECS
PC1 RPG7982 PACKING CASE 1 ECK
PC1 RPG7911 PACKING CASE 1 EGS
PC1 RPG7981 PACKING CASE 1 EGK
PC2 RPN1863 CUSHION 1
PC3 RPFD0004 MIRAMAT BAG 1
17. Schematic Diagram for printing with A4
