P2 Specifications
P2 Specifications
AJ-P2C008HG/AJ-P2C004HG
MEMORY CARD (P2 CARD)
Common Specification
Interface: CardBus (PC Card standards)
Power Source: DC3.3V ±0.3V
Power Consumption: Approx. 1.5W
Operating Temperature: –20°C to 60°C
Operating Humidity: 5% to 90% (no condensation)
Storage Temperature: –40°C to 80°C
Storage Humidity: 5% to 90% (no condensation)
Weight: 45 g
Dimensions: 54 x 5 x 85.6 mm
AJ-P2C008HG Specifications*
1
Recording Capacity:*
2
Approx. 8GB
Reading/Writing Speed:*
3
640 Mbps
Recording Playback Time: DVCPRO HD: Approx. 8 min. (Video/8CH audio)
DVCPRO 50: Approx. 16 min. (Video/4CH audio)
DVCPRO/DV: Approx. 32 min. (Video/2CH audio)
AJ-P2C004HG Specifications
Recording Capacity:*
2
Approx. 4GB
Reading/Writing Speed:*
2
640 Mbps
Recording Playback Time: DVCPRO HD: Approx. 4 min. (Video/8CH audio)
DVCPRO 50: Approx. 8 min. (Video/4CH audio)
DVCPRO/DV: Approx. 16 min. (Video/2CH audio)
*1. The upgrade of the P2 equipment is necessary to use 8GB P2 cards.
*2 Total card capacity includes space for data management such as system data, therefore, actual
usable area is less than capacity indicated on the card.
*3 This data transfer speed is theoretical value. An actual data transfer speed varies according to
operating condition and devices.
AJ-SPC700
MEMORY CARD CAMERA-RECORDER (P2 CAM)
General Specification
Power Source: DC 12V (11.0V to 17.0V)
Power Consumption: 17W (without option, LCD monitor off)
Operating Temperature : 0°C to 40°C
Storage Temperature: –20°C to 60°C
Operating Humidity: 10% to 85% (relative humidity)
Continuous Operation Time: Approx. 160 min. without option, LCD monitor off
and using AntonBauer Hytron50 battery
Weight: Approx. 4.1 kg (9.26 lbs)
(main unit only, without VF mount)
Dimensions (W x H x D): 137 x 209 x 318 mm (5-3/16" x 8-1/2" x 12-91/2")
without handle and wireless option cover
Camera Section
Image Sensor: 2/3" IT-CCD x 3
NTSC: 520,000 pixels, PAL: 600,000 pixels
Optical Filters: 1: 3200K 2: 5600K+1/8ND
3: 5600K 4: 5600K+1/64ND
Quantizing: 14 bit linear/18 MHz
Digital Signal Processing: 36 MHz
Horizontal Drive Frequency: 18 MHz
Programmable Gain: –3/0/+3/+6/+9/+12/+15/+18/+21/+24/+27/+30 dB
selectable 3-position (L/M/H)
Super Gain: +30/+36 dB selectable
Shutter Speed: NTSC: 1/100,1/120/,1/250,1/500,1/1000,1/2000 sec
PAL: 1/60,1/120/,1/250,1/500,1/1000,1/2000 sec
Syncro Scan Shutter: NTSC: 1/60.3 to 1/249.7 sec
PAL: 1/50.4 to 1/248.0 sec
Lens Mount: 2/3” bayonet type
Optical System: F 1.4 prism system
Sensitivity: F11.0 at 2000 lux, 89.9% reflect
Minimum Illumination: 0.5 Lux at F1.4, +36dB gain
Video S/N: NTSC: better than 64dB (standard)
PAL: better than 62dB (standard)
Horizontal Resolution: 750 TV lines at center, standard
Vertical Resolution: NTSC: 400/450 lines (super V),
PAL: 450/500 lines (super V)
Registration: Less than 0.05% (whole zone, without lens distortion)
LCD Monitor: 3.5” 200,000-pixels LCD color monitor
Memory Card Recorder Section
Video Recording Format: DVCPRO 50/DVCPRO/DV switchable
Audio Recording Format: 48kHz/16bits PCM audio, max. of 4CH
*CH1&2 same audio will be recorded on to CH3&4
Recording Media: P2 card
Recording/Playback Time*: [25 Mbps video and 2CH audio]
[DVCPRO/DV] by single cards using 5 card slot
AJ-P2C004HG Approx. 16 min. Approx. 80 min.
Recording/Playback Time*: [50 Mbps video and 4CH audio]
[DVCPRO 50] by single cards using 5 card slot
AJ-P2C004HG Approx. 8 min. Approx. 40 min.
Video Specification (when played back with standard player, component out)
NTSC Bandwidth: Y: 30 Hz to 5.75 MHz, +1.0/–3.0 dB (DVCPRO 50)
(AJ-SPC700P) PB/PR: 30 Hz to 2.75 MHz, +1.0/–3.0 dB (DVCPR O50)
PAL Bandwidth: Y: 25 Hz to 5.75 MHz, +1.0/–3.0 dB (DVCPRO 50),
(AJ-SPC700E) PB/PR: 25 Hz to 2.75 MHz, +1.0/–3.0 dB (DVCPRO 50)
S/N Ratio: Better than 55 dB
Audio Specification (when played back with standard player)
Sampling Frequncy: 48 kHz (sync. with video)
Quantizing: 16 bits
Frequncy Response: 20 Hz to 20 kHz, ±1.0dB (reference level)
Dynamic Range: More than 85 dB (1 kHz, AWTD)
Distortion: Within 0.1% (1 kHz, reference level)
Headroom: NTSC: 20 dB, PAL: 18 dB
Input and Output
GENLOCK IN: BNC, 1.0 Vp-p, 75 Ω (switchable to VIDEO IN)
CAM OUT: BNC, 1.0 Vp-p, 75 Ω
VIDEO OUT: BNC, 1.0 Vp-p, 75 Ω
AUDIO IN: XLR 3-pin x 2 (CH1/CH2),
LINE/MIC/MIC+48V switchable,
LINE: –3/0/+4 dBu selectable,
MIC: –60/–50 dBu selectable,
MIC+48V: Phantom +48 V, –60/–50 dBu selectable
MIC IN: XLR 3-pin, balanced, 3 kΩ, –50/–40 dBu selectable,
Phantom +48 V ON/OFF
WIRELESS IN: D-sub 25-pin, –40 dBu
AUDIO OUT: XLR 3-pin, balanced, low-impedance,
–3/0/+4 dBu selectable
PHONES OUT: Stereo Mini Jack x 2
TC IN: BNC, 0.5 to 8 Vp-p, 10 kΩ
TC OUT: BNC, low-impedance, 2.0±0.5 Vp-p
DC IN: XLR 4-pin, DC 12 V (DC 11.0 V to 17.0 V)
DC OUT: 4-pin, DC12 V (DC11.0 to 17.0 V), Max. 1A
LENS: 12-pin
EVF: 20-pin
ECU: 6-pin (for AJ-EC3P)
Included Accessories
Shoulder strap, Front audio volume knob, Screw M2 x 6 mm (XYNZ+J6FZ)
