P2 Specifications
P2 Specifications
• Composite IN/Composite OUT
Video Bandwidth (625i): Y: 25 Hz to 5.5 MHz (–3.0 dB)
Video Bandwidth (525i): Y: 30 Hz to 5.5 MHz (–3.0 dB)
Y/C Delay: less than 20 nsec
Video Input Signal
Analogue Component In: BNC x 3 (Y,PB,PR) Y: 1.0 Vp-p, 75Ω,
PB/PR (625i): 0.7 Vp-p, 75Ω (100% colour bar)
PB/PR (525i): 0.486/0.7 Vp-p switchable, 75Ω
(75% colour bar, 7.5% setup)
Analogue Composite In: BNC x 2 (loop-through), 75Ω on/off,
Video: 1.0 Vp-p (75Ω)
Reference Input: Analogue composite, BNC x 2 (loop-through),
75Ω on/off
SDI Input (option ): BNC x 2 (active-through), serial digital component
ITU-R BT.656-4 (PAL),
SMPTE259M-C (NTSC) standard
Video Output Signal
Analogue Component Out: BNC x 3 (Y,PB,PR) Y: 1.0 Vp-p, 75Ω,
PB/PR (625i): 0.7 Vp-p, 75Ω (100% colour bar)
PB/PR (525i): 0.486/0.7 Vp-p switchable, 75Ω
(75% colour bar, 7.5% setup)
Analogue Composite Out: BNC x 3, Video 1/Video 2 (Video/WFM selectable)
Video 3 (superimpose on/off)
SDI Output (option ): BNC x 3, SDI1, SDI2, SDI3 (superimpose on/off)
ITU-R BT.656-4 (PAL),
SMPTE259M-C (NTSC) standard
Video Output Adjustment Range
Gain: ±3 dB
Chroma Gain: ±3 dB
Hue (Chroma Phase): ±30°
Set-up Level (Black Level): ±14 IRE (±100 mV)
Sync Phase: ±15 µsec
SC Phase: ±180°
Audio Specification (Digital Audio )
Sampling Frequncy: 48 kHz (sync video)
Quantizing: 16 bits
Frequncy Response: 20 Hz to 20 kHz, ±1.0 dB (reference level)
Dynamic Range: More than 90 dB (1 kHz, emphasis off, “A” weighted)
Distortion: Less than 0.05% (1 kHz, emphasis off, reference level)
Cross Talk: Less than –80 dB (1 kHz, between 2 channels)
Wow & Flutter: Below measureble limit
Headroom: 18 dB (PAL), 20 dB (NTSC)
De-emphasis: T1=50 µsec, T2=15 µsec (on/off auto)
Audio Input Signal
Analogue Input: XLR x 4 (CH1/CH2/CH3/CH4),
600Ω/high-impedance switchable,
+4/0/–20 dBu switchable
Digital Input: BNC x 2 (CH1/2, CH3/4), AES/EBU format
Serial Digital Input: BNC x 2 (active through), 75Ω
ITU-R BT.656-4 standard (PAL)
SMPTE259M-C/272M-A standard (NTSC)
Audio Output Signal
Analogue Output: XLR x 4 (CH1/CH2/CH3/CH4), low-impedance,
+4/0/–20 dBu switchable
Digital Output: BNC x 2 (CH1/2, CH3/4),
AES/EBU format, 1.0±0.2 Vp-p 75Ω
Serial Digital Output: BNC x 3, 75Ω
ITU-R BT.656-4 standard (PAL)
SMPTE259M-C/272M-A standard (NTSC)
Monitor Output: XLR x 2, low-impedance, +4/0/–20 dBu switchable
Headphones: Stereo mini jack, 8Ω, variable level
Other Input and Output
Time Code Input: XLR x 1, 0.5 to 8.0 Vp-p, 10 kΩ
Time Code Output: XLR x 1, low-impedance, 2.0±0.5 Vp-p
RS-422A Input/Output: D-sub 9-pin, RS-422A Interface
RS-232C: D-sub 25-pin, RS-232C Interface
Encoder Remote: D-sub 15-pin
AJ-PCS060G
PORTABLE HARD DISK UNIT (P2 STORE)
General Specification
Power Source: DC 7.2 V with battery pack
DC 7.9 V with AC adaptor
Max. 1.3 A (0.8 A when standard oparation)
Permissible Temperature: Operating: 0°C to 40°C
Storage: –20°C to 60°C
Permissible Humidity: Operating: 5% to 85% (no condensation)
Storage: 0% to 90% (no condensation)
Weight: Approx. 0.65 kg
Dimensions (W x H x D): 90 x 45 x 180.5 mm
Hard Disk Drive
HDD Capacity: 60 GB
PC Operating System: Proper operation guaranteed
Windows XP Professional (later SP2)
Windows 2000 (later SP4)
Mac OS X (10.4.2, 10.4.6)*
PC Interface: USB Ver. 2.0 compliant, reed only
Card Slot
PC Card Slot: for P2 Card (AJ-P2C002SG/P2C004HG) x 1 slot
(CardBus compliant)
*Mac of the Intel CPU base is not supported.
AJ-PCD20
MEMORY CARD DRIVE (P2 DRIVE)
General Specification
Power Source: AC 100 V to 240 V (0.9A to 0.5A), 50/60 Hz
DC 16 V (0.8 A) with AC adaptor
DC 12 V (1.0 A) when PC built-in
Operating Temperature: 0°C to 40°C
Operating Humidity: 0% to 90% (no condensation)
Weight: Approx. 1.2 kg (2.64 lbs)
Dimensions (W x H x D): 148.4 x 42.5 x 199.5 mm
excluding protruding parts
PC System Requirement
Operating System: Windows XP Professional (later SP2)
Windows 2000 (later SP4)
Mac OS X (later 10.3.9, later 10.4.2)
Main Memory: 512 MB or greater recommended
Interface: IEEE 1394b and USB Ver. 2.0 compliant
Card Slot
PC Card Slot: PC Card (Type II) x 5 slot (CardBus compliant)
