Panasonic EP-MA03

EN7
English
Controller
1 Display
This illustration is when all lamps are illuminated.•
2
Off/On button
Switches the controller on and off.•
3
Menu Selection buttons
4 Up/Down ( / ) - Adjustment buttons
Left/Right (
/ ) - Adjustment buttons
5
Quick Stop button
Press this button to stop the massage immediately.•
6
O.K. button
7 Leg/foot Massage Off/On button
Switches the leg/foot massage on and off. •
(See page EN21.)
8 Leg/foot Air Intensity buttons
9 Sole Heat Off/On button
10 Reclining Angle Adjustment button
Leg/foot Massage Section Angle Adjustment button
Display
1
“FULL BODY” Display
When selecting a program: •
The mark for the currently selected program is displayed.
During the massage: •
The current program is displayed.
2
“SELECTED AREA” Display
When selecting a program: •
The mark for the currently selected program is displayed.
During the massage: •
The current program is displayed.
3
Leg/Foot Air Massage Intensity Display
Displays intensity of current leg/foot massage in 3 •
levels.
4
Shoulder Position Display
Flashes in shoulder position adjustment mode •
(Approx. 15 seconds)
Lights up while the "FULL BODY" and "SELECTED •
AREA" programs are operating to display the shoulder
positions.
5
Massage Head Position Display
Displays current approximate position of massage •
heads.
6
Massage Operation Display (See page EN19.)
7
Width Display
When using the operation in which the width can be •
adjusted in the
mode, displays the current
spans during massages.
Narrow width / Widen width
8
Heat Operation Display
Displays the on/off status of the sole warmth.•
If the set temperature is exceeded, the double line on •
to being steadily lit.
3
7
6
5
10
9
2
8
4
7
6
5
4
1
2
3
8
1
