Panasonic EP3203-U1 - Page 28

Caution when installing
When installing the Under covers, be sure to confirm that the Under covers do
not pull or crush the Air hoses, and move the Ottoman to confirm that the
Ottoman does not pull anything.
10.2.3. Removing the Side cover
1. Follow the procedure 10.2.1 Removing the Rear cover and 10.2.2. Removing the
Under cover.
2. Unscrew three srew-rivets.
28
