Panasonic ER154-E8 - Disassembly Instructions

Follow the procedure below to disassemble the main body.
1. Remove the attachment.
2. First, hold the handle of the hair clipper firmly with the
"Panasonic" name facing upward and set the dial to
"2.0mm", and push the upper part of the blade away from
the housing.
3. Loosen two screws tightening the spring for cutter and take
out the spring.
4. Remove the front panel.
5. With the dial at “ 2.0mm” , slide up the adjusting dial to the
blade side slightly pushing the adjusting arm with the
slotted-head screwdriver.
6. Loose a screw and take out the bottom cover.
