6 EXPLODED VIEW
7 REPLACEMENT PARTS LIST
Ref. No. Part No. Part Name & Description Remarks Per Unit
1 WER9792Y BLADE BLOCK 1
2 WER151L9207 TAPPING SCREW *C K2.6-8 2
3 WER154L0168 SPRING FOR CUTTER 1
4 WER154S3968 FRONT PANEL 1
5 WER154S3288 ADJUSTING DIAL 1
6 WER150L0137 DUST-PROOF RUBBER 1
7 WER154K3058 HOUSING A 1
8 WER154L0458 DIAL CLICK BUTTON 1
9 WER154L0158 DIAL CLICK SPRING 1
10 WER154L3178 HOLDING PLATE 1
11 WER154L3578 SWITCH CONTACT PLATE 1
12 WER154L1008 MOTOR 1
13 WER154L0778 CHASSIS BLOCK 1
14 WER154L2108 MODULE 1
15 WER154K2158 PLUG BLOCK 1
16 WER154L2508 RECHARGEABLE BATTERY *B Ni-Mh Type (2PCS/PK) 2
17 WER154K3068 HOUSING B 1
18 WER154K8408 NAME PLATE 1
19 WER160L9207 P-TIGHT SCREW M2.0-8 1
20 WER154K3178 BOTTOM COVER 1
21 WER160L9107 SCREW M2-6 1
22 WER154K7398 COMB ATTACHMENT A 3-4MM 1
23 WER154K7408 COMB ATTACHMENT B 6-9MM 1
24 WER154K7418 COMB ATTACHMENT C 12-15MM 1
25 WER154K7188 CHARGING STAND 1
26 WER154K7198 CHARGING STAND TRAY 1
27 WER154K7659 CHARGING ADAPTOR C-2 PLUG 1
28 WES76806761 CLEANING BRUSH 1
29 WER203X7918 OIL 1
- WER154K8008 INDIVIDUAL BOX 1
- WER154K8108 OPERATING INSTRUCTIONS 1
8
ER154-E8
