5
English
Cleaning with the brush
Clean the inner blade using the short brush by
moving it in direction (A).
Clean the outer foil and the shaver body using
the long brush.
Do not move the short brush in direction (B)
as it will damage the inner blade and affect
its sharpness.
Do not use the short brush to clean the outer
foils.
•
•
Replacing the outer foil and the inner blade
outer foil once every year
inner blade once every two years
Replacing the outer foil
1. Press the foil frame release button and lift
the outer foil section upwards.
1
2. Gently push the outer foil in the way as
illustrated. Then it will pop up from the foil
frame.
2
3. The new outer foil should be slightly bent
and pushed in until it is hooked in the foil
frame.
3
Replacing the inner blade
1. Press the foil frame release button and lift the
outer foil section upwards.
1
2. Remove the inner blade.
Do not touch the edges (metal parts) of the
inner blade to prevent injury to your hand.
3. Insert the inner blade until it clicks.
•
Replacement parts
Replacement parts are available at your dealer or Service Center.
Replacement parts for
ES-RC30
Outer foil WES9941
Inner blade WES9942
ES-RC30_TW.indb 5 2014/03/05 14:04:36
