Parts identification





















Front
Back









  







A Main body
1 Protective cap
2 System outer foil
3 Foil frame
4 Foil frame release buttons
5 Thumb rest
6 Power switch
7 Battery capacity lamp ( )
8 Charge status lamp ( )
9 Appliance socket
: Outer foil section
; System outer foil release
buttons
< Inner blades
= Trimmer
> Trimmer handle
? Lock release button
B Self-cleaning recharger
@ Arm
A Charging terminal
B Cleaning liquid unit
removal button
C Self‑cleaning recharger socket
 Lock release lever
E Cleaning liquid filter
 Water maximum line
 Cleaning liquid unit
H STATUS lamp
I AUTO lamp
J SELECT button
C AC adaptor (RE7-59)
K Adaptor
L Power plug
M Cord
N Appliance plug
D Comb attachment
 Comb
 Trimming height window
 Comb attachment release
buttons
 Trimming height switch
button
Accessories
E Special detergent
(Detergent)
F Oil
