Panasonic ES-WL50 - Parts Identification; Outer Foil Assembly; Main Body and Controls; Attachments and Accessories

8
English
CAUTION
Always follow the cautions
printed on the batteries�
Check the polarity of the
batteries (+ and -) and
install them correctly.
Do not mix old batteries with
new ones, and do not mix
batteries of different types.
Remove the batteries
immediately and dispose of
them safely when they are
discharged�
Remove the batteries when
not using the appliance for
an extended period of time�
Use the batteries by the
recommended use-by date.
‑ Failure to do so may cause
overheating or explosion of
the batteries, injury or
contamination of
surroundings due to leakage.
Parts identication (Fig. 1)
A Protection cap
Always attach the protection cap
after use to prevent the outer foil
from becoming damaged.
B Outer foil frame
1 Outer foil
2 Pop‑up trimmer
3 Pop‑up trimmer switch
C Inner blade
D Main body
4 Frame release buttons
5 Lock button
6 Power switch [0/1]
7 Battery cover
E Bikini comb
This comb shortens long pubic hair.
Accessory:
F Cleaning brush
Batteries are not supplied. Please
purchase them separately.
Installing or replacing
the batteries (Fig� 2)
1
1
Make sure the power switch
is in the “0” position�
2
2
Pull the battery cover
straight to remove it�
3
3
Check the polarities of the
batteries, and install two
batteries�
• The batteries may not t in
perfectly. Attaching the battery
cover helps the batteries to t in.
4
4
Attach the battery cover.
• Press rmly until it clicks.
•
If the main body is wet,
thoroughly wipe it to prevent
water droplets from getting inside.
Notes
• You can use the appliance for
approximately 1 month with two
Panasonic LR03 (AAA alkaline
batteries).
(When used for approx. 5 minutes
at one time, once every 3 days, in
a room temperature of 20 °C)
•
Use only LR03 (AAA alkaline
battery).
(The power or number of uses may
vary if other batteries are used.)
• Do not use rechargeable batteries.
ES-WL50_EU v5.indb 8 18/11/30 下午6:17
