7
SPECIFICATIONS
CORDLESS DRILL & DRIVER (EY6220/EY503)
Motor DC Motor 2.4 V
No load speed
LOW: 200 min
-1
(rpm)
HIGH: 400 min
-1
(rpm)
Hexagonal driving shaft 6.35 mm, (1/4″) across flats
Maximum drilling dia. for metal 2 mm (5/64″)
Maximum torque
LOW: 2.9 Nm (30 kg-cm, 26 in.lbs)
HIGH: 1.5 Nm (15 kg-cm, 13 in.lbs)
Maximum clutch torque 2.0 Nm (20 kg-cm, 17.5 in.lbs) at 5 position
Overall length 239 mm (9-3/8″)
Weight (with battery pack) 0.4 kg (0.9 lbs)
BATTERY PACK (EY9021/EY903)
Storage battery Ni-Cd battery
Battery voltage 2.4 V DC (1.2 V × 2 cells)
BATTERY CHARGER (EY0020/RE503)
Input 120, 220, 230, 240 V AC separately available
Charging time Standard 1 hour
Mass (Weight) 0.7 kg (1.54 lbs)
NOTE: For applicable battery packs to this charger, see the label on the charger or the latest general
catalog.
