Panasonic FV-0511VH1

10
No.
Part No. Part Name Q´ty Remark
19 FFV51VHL1900 Main PCB Box
1
20 FFV510VS1M9 Speed Switch 1
21 FFV51VHL199 Main PCB Cover 1
22 FFV51VHL131 Power Lead Wire 1
23 FFV51VHL132 Motor Lead Wire 1
24 FFV51VHL135 SP Motor Lead Wire 1
E FFV7000145S Pan Tap Screw 6
No.
Part No. Part Name Q´ty Remark
25 FFV51VHL1930 Damper
1
26 FFV51VHL1908 Casing Adapter
1
27 FFV30BU10908 Joint
1
28 FFVMSFJC20A SP Motor
1
E FFV7000145S Pan Tap Screw 1
No.
Part No. Part Name Q´ty Remark
29 FFV51VHL1708 Mesh Holder
1
30 FFV51VHL1707 Mesh
1
31 FFV51VHL1702 Heater Cover
1
32 FFV51VHL1710 PTC Heater Assy
1
33 FFV51VHL1720 Thermostat 1
B FFV7000089S Truss Tap Screw 6
E FFV7000145S Pan Tap Screw 1
Casing Adapter Unit
Main PCB Unit
Heater Unit Assy
4. Parts List
FV-0511VH1
!
!
!
!
!
!
!
!
!
