Panasonic FV-08VS1 - Page 2

FV-05VS1
FV-08VS1
These Panasonic ceiling mount ventilation fans use a sirocco fan driven by a capacitor motor. The motor
is designed to have an extended service life with reduced energy consumption. It also incorporates a
thermal-cutoff for safety. The grille covering the main body is a spring-loaded, quick-release type. A damper
for preventing counterflow is provided.
1
8
1
Thumb screw
Long screw
(M4X30)
Quantity
Appearance
Part name
Grille
Suspension
bracket I
Suspension
bracket II
1
1
Screw
(M4X8)
I
2
1
Suspension
bracket III
Screw
(M4X10)
II
2
Spacer
1
