4. Parts List
FV-10VE2
No. Part No. Part Name Q'ty Remark
1 FFV1600176S Frame Body Assy 1
2 FFV0720012S Cord Bushing 1
3 FFV4620115S Power Cord 1
4 FFV6710047S Wiring Cover 1
5 FFV3740038S Maintenance Plate 1
6 FFV4300151S OA Damper Assy 1 Include Temperature Sensor
7 FFV3402189S EA Fan Assy 1
8 FFV3702280S SA Fan Assy 1
9 FFV1600153S Frame Bracket Assy 1
10 FFV1600154S Frame Bracket Hook 1
11 FFV3402190S Element Assy 1
12 FFV3402191S Element Holder 1
13 FFV6730102S RA Filter 1
14 FFV4300152S OA Filter M8 1 Merv 8
(14) FFV4300157S OA Filter M13 1 Merv 13
15 FFV1600175S Frame Cover Assy 1
A FFV7000074S Truss Tap Screw 14
B FFV7030008S Pan Screw 2
C FFV7000224S PS Screw 6
D FFV7000089S Truss Tap Screw 2
No. Part No. Part Name Q'ty Remark
16 FFV3440021S Latch 2
17 FFV2220075S Hinge B 2
18 FFV0000163S Adapter 2
A FFV7000074S Truss Tap Screw 16
No. Part No. Part Name Q'ty Remark
19 FFV3730127S Motor Holder Plate 1
20 FFV2230022S Holder Gum(B) 1
21 FFV3402192S EA Motor Assy 1
(21) FFV3702281S SA Motor Assy 1
22 FFV2230023S Holder Gum(A) 1
23 FFV3730128S Motor Holder 1
24 FFV4710408S Casing Packing 1
25 FFV3730129S Motor Base 1
26 FFV7010055S Washer 1
27 FFV1610079S Fan Assy 1
Main Body Section
Frame Body Assy
SA Fan Assy/EA Fan Assy
