Panasonic FV-10VEC2R - Filter and Core Maintenance

18
MAINTENANCE
3.Clean energy recovery core with vacuum
cleaner. (Fig.23)
5.Reinstall and close frame cover by locking the
latches, then reset the lock plate. (Fig.25)
6.Connect power, press filter reset button
with sound of “beep”, then filter indicator
and buzzer sound will be off. (Fig.26)
4.Replace the OA and RA filters.
Make sure the RA filter adapts to the convex
and the direction of the arrow on the OA
filter is in the same direction as the air flow
displayed on the nearby label. (Fig.24)
Fig.24
OA filter
Convex
RA filter
Lock plate
Latch
Main
switch
Filter reset
button
AIR FLOW
AIR FLOW
Fig.23
Energy recovery
core
Fig.25
2
1
Fig.26
I
O
10
20
30
40
50
60
50
60
70
80
90
100
50
60
70
80
90
100
Supply
Air
Air fourni
(CFM)
(CFM)
min/h
min/h
Exhaust Air
Air
d'évacuation
Filter
Reset
Button
Bouton de
réinitialisation
du filtre
(pi
3
/min)
(pi
3
/min)
2.Remove OA filter and RA filter to clean with
vacuum cleaner. (Fig.22)
It is suggested to replace the OA filter every
6 months. Please fill in beginning time on
new OA filter before replacing.
Please replace OA filter by Panasonic Model
FV-FL0810VE1or FV-FL1310VE1.
Note
OA filter
RA filter
Step
Step
Fig.22
BEGINNING TIME:
1
2
