Panasonic FV-10VEC2R - DIMENSIONS

Unit:inches(mm)
5
DIMENSIONS
(150) Dia.
5 15/16 Dia.
(353.3)
13 7/8
(347.4)
13 11/16
13/16
(20.8)
12345
35 13/16 (909.6)
28 1/2 (723.6)
3 15/16
(99.2)
678910
1112
13
14
19
20
17 181615
RA
(100) Dia. 3 15/16 Dia.
(151) Dia.
5 15/16 Dia.
OA
(100) Dia. 3 15/16 Dia.
(117.9) 4 11/16
EA
(584.6)
23
8 7/8 (225.6)
EA: Exhaust air
OA: Outside air
SA: Supply air
RA: Return air
Part nameNo. Part nameNo.
Frame cover
Power cord
(length 70 7/8 (1800))
EA adapter
EA damper assy.
EA fan assy.
DC motor
Frame body
Maintenance plate
Wiring cover
1
2
3
4
5
6
7
8
9
SA adapter
RA filter
OA filter
RA adapter
OA adapter
Energy recovery core
Plug
OA damper assy.
Center damper assy.
SA fan assy.
Control panel
10
11
12
13
14
15
16
17
18
19
20
SA
