No. Part No. Part Name Q'ty Remark
1 FFV3400112S Grille Unit 1
2 FFV0930008S Circulation Unit 1
3 FFV6400002S Ventilation Unit 1
4 FFV1600088S Frame Unit 1
A FFV7000153S Truss Tap Screw 4 For Fixing Circulation Unit
B FFV7000080S Plus Truss Screw 3 For Fixing Ventilation Unit
C FFV2530003S Tie 1 1
No. Part No. Part Name Q'ty Remark
5 FFV0000083S Adaptor Assy. 1
6 FFV0420025S Bracket Cover 1 1
7 FFV1600089S Frame Assy. 1
8 FFV0420013S Bracket Cover 1
9 FFV3400113S Grille Fix Plate 2
10 FFV2800009S Junction Box Assy. 1
11 FFV2800010S Junction Box Cover 1
12 FFV0900038S Connector Wire V 1
13 FFV0900026S Connector Wire C 1
14 FFV1300006S Earth Lead Wire 1
A FFV7000153S Truss Tap Screw 16
D FFV7010002S Plain Washer 1
E FFV7010028S Spring Washer 1
F FFV7000006S Bind Screw 1 For Fixing Earth Lead Wire
G FFV7000011S Machine Screw 1 For Fixing Junction Box Cover
No. Part No. Part Name Q'ty Remark
15 FFV3400114S
Heater Cover 1
16 FFV5560038S
Spring Set Plate 1 1
17
FFV5560039S Spring 2
18
FFV5560040S Spring Set Plate 1
19
FFV5560041S Spring Set Plate 2 1
H FFV7000170S Truss Screw 1 For Fixing Spring Set Plate 1
I FFV7000055S Pan Tap Screw 2 For Fixing Spring Set Plate
No. Part No. Part Name Q'ty Remark
20
FFV0790055S Casing Section
1
21 FFV4700012S PCB Box 1
22 FFV4700013S PCB Set 1
23 FFV4700014S PCB Box Cover 1
24
FFV2220014S Heater Section
1
A FFV7000153S Truss Tap Screw 3 For Fixing Casing Section
J FFV7000172S Truss Tap Screw 2 For Fixing PCB Box Cover
K FFV7000009S Truss Tap Screw 2 For Fixing PCB Box
L FFV7000171S Truss Tap Screw 2 For Fixing PCB Set
Main Body Section
Grille Unit
Frame Unit
Circulation Unit
!
To Next Page
