4. Parts List
FV-20VEC1
No. Part No. Part Name Q'ty Remark
33 FFV4300135S Orifice 2
34 FFV7020022S Nut 2
35 FFV0400140S Blade 2
36 FFV3740062S Motor Holder 2
37 FFE08112001S Holder Gum (A) 2
38 FFV1610107S EA Moter 1
39 FFE08121701S Holder Gum(B) 2
40 FFV1600178S Frame Body 1
41 FFV0000192S Adapter Assy 2
42 FFV0720014S Cord Bushing 1
43 FFV3740063S Maintenance Plate 2 1
44 FFV6710059S Wiring Cover Assy 2
45 FFV3740064S Maintenance Plate 1 1
46 FFV5690035S Side Panel Assy 2
47 FFV3740065S Motor Base 1
48 FFV3740066S Motor Assy 1
49 FFV3740067S Motor Connector 3
50 FFV0790137S Casing Assy 1
A FFV7000074S Truss Tap Screw 36
No. Part No. Part Name Q'ty Remark
11 FFV5500042S Sensor Cap 1
12 FFV0010275S Humidity Sensor 1
51 FFV0900063S Connector Cover 1
52 FFV3400175S Limit Switch Pad 1
53 FFV5530078S Switch PCB Cover 1
54 FFV5580017S Switch Assy 1
55 FFV5580010S Switch Knob 3
56 FFV5580011S Switch Spring 3
57 FFV5530079S Switch PCB Assy 1
58 FFV5530080S Switch PCB Base 1
59 FFV1610108S RA HUM Sensor Wire 1
60 FFV4700105S PCB Box 1
61 FFV0000164S AHU Wire 1
Frame Section
PCB Box Section
