4
2 Structure
2.1 Multiple-function Combination Cable
You can refer to the following figure for multiple-function combination cable information. See Figure
2-1.
Figure 2-1 Multiple-function combination cable
No.
Port Name
Function
Connection
Note
1.
LAN
Network port
Ethernet
Connect to standard Ethernet cable.
2
DC12V
Power input
port
Power input port. Input DC 12V.
