Setting Up
17
Setting up the base unit
Connecting the base unit
Important:
L Use only the supplied Panasonic AC adaptor PQLV219 or PQLV219 (03).
L KX-TGP550 only: Do not connect the Ethernet cable connected to the PoE hub to
the PC port of the unit. Doing so may cause severe damage to the unit.
KX-TGP500
(120 V AC, 60 Hz)
AC adaptor
To a hub/router
Ethernet cable
Hook
B
C
Press plug firmly.
“Click”
A
Correct
Base
unit
Base
unit
Wrong
