Panasonic LUMIX DC-FZ80 Basic Operating Instructions

52
Others
DVQX1158 (ENG)
Q&A
Troubleshooting
• Performing [Reset] in the [Setup] menu may resolve the issue.
• Further information is provided in the “Operating Instructions for advanced
features (PDF format)”. Check it together with the information in this section.
The charging lamp blinks.
• Charging is being performed in a place with extremely high or low temperature.
→ Reconnect the USB connection cable (supplied) and retry charging in a place where
ambient temperature is 10 °C to 30 °C (50 °F to 86 °F) (temperature conditions also
apply to the battery itself).
• Charging is not possible if the power supply capacity of the computer is low.
The battery runs down quickly.
• [4K PHOTO] is set to [ ] ([4K Pre-Burst]).
→ When [
] ([4K Pre-Burst]) has been selected, the battery drains faster.
Select [
] ([4K Pre-Burst]) only when recording.
Focus not aligned correctly.
• Subject outside of focus range.
• [Focus/Release Priority] is set to [RELEASE]. (→42)
• [Shutter AF] is set to [OFF]. (→42)
• AF Lock is set inappropriately.
• If there are fingerprints or dirt on the lens, the focus may be set to the lens and not the
subject.
Subject appears skewed in pictures.
• If you take a picture of a moving subject in the electronic shutter mode, motion picture
recording mode, or 4K photo recording mode, the subject in the picture may be skewed
in some cases. This is characteristic of MOS sensors which serve as the camera’s pickup
sensors. This is not a malfunction.
Striping or flicker may appear under lighting such as fluorescent lighting
and LED lighting fixture.
• This is characteristic of MOS sensors which serve as the camera’s pickup sensors. This is
not a malfunction.
• If you are taking still pictures using the electronic shutter, the striping may be reduced by
setting a slower shutter speed.
• When noticeable flicker or striping is seen under lighting such as a fluorescent or LED lighting
fixture in the motion picture recording mode, you can reduce the flicker or striping by setting
up [Flkr Decrease] (→41) and fixing the shutter speed. It is possible to select a shutter speed
from [1/50], [1/60], [1/100], or [1/120]. You can set the shutter speed manually in the Creative
Video Mode. (→19)

Panasonic LUMIX DC-FZ80 Specifications

General

Megapixel	18.9 MP
Camera type	Bridge camera
Sensor type	MOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4896 x 3672 pixels
Still image resolution(s)	4896 x 3672
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Night
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Digital zoom	4 x
Optical zoom	60 x
Number of aspheric elements	6
Lens structure (elements/groups)	14/12
Maximum focal length (35mm film equiv)	215 mm
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	895 mAh
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 6.1 m
Flash range (wide)	0.3 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC
Resolution at capture speed	640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Cables included	AC

Weight and Dimensions

Depth	119.2 mm
Width	130.2 mm
Height	94.3 mm
Weight	616 g
