Panasonic Lumix DC-G9 Owner's Manual

19
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1310
• Check that the camera is turned off.
• Push it securely all the way until you hear a click while being careful about the direction in
which you insert it.
To remove the card, push the card until it clicks, then pull the card out upright.
∫ Card access indicators
Access indication
Lights up red while an image is being recorded to the card.
• During access (image writing, reading and deleting, formatting etc.),
do not turn this unit off, remove the battery, card or disconnect the AC
adaptor. Furthermore, do not subject the camera to vibration, impact
or static electricity.
• Change lenses where there is not a lot of dirt or dust.
• Do not press the lens release button A when you attach a lens.
∫ Detaching the lens
1 Attach the lens cap.
2 While pressing on the lens release button B, rotate the
lens toward the arrow until it stops and then remove.
3
Inserting the Card (Optional)
4
Attaching/Removing the Lens
DC-G9BodyP-DVQX1310_eng.book 19 ページ ２０１７年１１月１３日 月曜日 午前９時５９分

Panasonic Lumix DC-G9 Specifications

General

Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	Venus Engine
Connectivity	Wi-Fi, Bluetooth
Weight	658 g (body only)
Lens Mount	Micro Four Thirds
Storage Media	Dual SD card slots (UHS-II compatible)
Sensor	Live MOS
ISO Range	ISO 200-25600 (expandable to 100-25600)
Autofocus System	Depth From Defocus (DFD) technology
Viewfinder	OLED Live View Finder, 3, 680k-dot
LCD Screen	3.0" 1, 040k-dot Free-Angle Touchscreen
Video Recording	4K UHD at 60p
Image Stabilization	5-axis in-body stabilization
Burst Shooting	20 fps (electronic shutter)
Battery Life	Approx. 400 shots
Ports	HDMI, USB 3.0
Battery	DMW-BLF19 Lithium-Ion
Dimensions	136.9 x 97.3 x 91.6 mm
Weather Sealing	Yes, Splashproof / Dustproof / Freezeproof
