Panasonic Lumix DC-GH5 Basic Operating Instructions

15
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1072
2 Press the shutter button halfway
to focus.
A Aperture value
B Shutter speed
C Focus indication
• Aperture value and shutter speed are
displayed.
(It will flash in red if the correct
exposure is not achieved, except
when set to flash.)
• Once the subject is in focus, the
focus indication is displayed. (When
the subject is not in focus, the indication flashes.)
3 Press the shutter button fully (push it in further), and take the picture.
• Be careful not to move the camera when you press the shutter button.
• Pictures cannot be taken until focus is achieved when [Focus/Release Priority] is set to
[FOCUS].
∫ Free angle shooting
The monitor can be rotated to suit your needs. This is convenient as it allows you to take
pictures from various angles by adjusting the monitor.
• To display the picture in Playback Mode, press [(].
Taking pictures at a high angle Taking pictures at a low angle
12
Check the picture you have taken
6060602.82.82.8
1/981/981/981/98
DC-GH5BodyGN-DVQX1072_eng.book 15 ページ ２０１７年２月１３日 月曜日 午前１１時４５分

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
