Recording
66
DVQX1072 (ENG)
5 Connect the HDMI cable to the [HDMI]
socket (8).
B Leave some slack so that this section has
a length of at least 10 cm (0.33 feet).
• You can also connect the HDMI cable and
USB connection cable at the same time
when the cable holder is attached.
Removing the cable holder
To remove the cable holder, follow the steps for attaching it in the reverse order.
• We recommend using an HDMI cable with a maximum thickness diameter of 6 mm (0.24 inch).
• Keep the clamp portion of the cable holder out of reach of children to prevent swallowing.
∫ Notes on images output via HDMI (sorted by Recording Mode)
∫ Setting the output bit value for 4K/60p (4K/50p)
Settings: [4:2:2 10bit]/[4:2:0 8bit]
• Motion pictures cannot be recorded to the card at [4:2:2 10bit] during HDMI output.
• This item works only when [Rec Quality] is set to [4K/8bit/150M/60p] or [4K/8bit/150M/50p] in
Creative Video Mode.
Recording
Mode
Aspect ratio
The output setting is determined by the
[Rec Quality] setting in the [Motion
Picture] menu.
• When [Anamorphic(4:3)] is set, black
bars appear on both sides of output
images.
The output setting is determined by the
[Aspect Ratio] setting in the [Rec]
menu.
• Black bars appear on both sides of
images, except for those with an
aspect ratio of [16:9].
Size/frame
rate
The output setting is determined by the
[Rec Quality] setting and the [Down
Convert] setting for [HDMI Rec
Output], both located in the [Motion
Picture] menu.
The output setting is determined by the
connected device.
Output bit
value
The output setting is determined by the
[Rec Quality] setting in the [Motion
Picture] menu.
• If [10bit] is not supported by the
connected device, the setting
changes to 8 bit.
• You can set the output bit value when
using a 4K/60p (4K/50p) setting.
The output setting is determined by the
connected device.
> [Motion Picture] > [HDMI Rec Output] >
[4K/60p Bit Mode] ([4K/50p Bit Mode])
DC-GH5BodyGN-DVQX1072_eng.book 66 ページ ２０１７年２月１３日 月曜日 午前１１時４５分
