Preparation/Basic “Quick Start Guide”
13
(ENG) DVQX1123
A Check the orientation of the card.
• Push it securely all the way until you hear a “click” while being careful about the direction
in which you insert it.
To remove the card, push the card until it clicks, then pull the card out upright.
• When attaching or detaching the interchangeable lens (H-FS12032), retract the lens
barrel.
• Change lenses where there is not a lot of dirt or dust.
• Do not press the lens release button A when you attach a lens.
∫ Detaching the lens
1 Attach the lens cap.
2 While pressing on the lens release button
B, rotate the lens toward the arrow until it
stops and then remove.
• Hold the part around the base of the lens to
rotate it.
3
Inserting the Card (Optional)
4
Attaching/Removing the Lens
DC-GX800EB-DVQX1123_eng.book 13 ページ ２０１６年１２月１日 木曜日 午後５時４９分
To Next Page
