Panasonic Lumix DMC-FS18 Basic Operating Instructions

5
(ENG) VQT3D41
∫ About the battery charger
•
The battery charger is in the standby condition when the AC power supply cord
is connected. The primary circuit is always “live” as long as the power cord is
connected to an electrical outlet.
∫ Cautions for Use
•
Do not use any other AV cables except the supplied one.
• Do not use any other USB connection cables except the supplied one.
Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (DMW-AC5E; optional). Then reinsert the battery or reconnect AC
adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
CAUTION!
• DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE
HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY
OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
• DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
• DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
• DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY
MANNER.
DMC-FS35&FS18&FS16&FS14EB-VQT3D41_eng.book 5 ページ ２０１０年１２月１６日 木曜日 午後５時２３分

Panasonic Lumix DMC-FS18 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Combined zoom	16 x
Focal length range	5 - 20 mm
Maximum aperture number	6.5
Minimum aperture number	3.1
Number of diaphragm blades	6
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	112 mm
Minimum focal length (35mm film equiv)	28 mm
Interface	PAL, USB 2.0
Digital SLR	No
Power source type	Battery
Power supply type	3.6 V
Dimensions (WxDxH)	94.3 x 18.8 x 53.5 mm
Camera shutter speed	8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Normal focusing range	0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery capacity	660 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	121 g
